Electric Stackers WSRX 15
PALLET STACKERS -WSRX15
Lithium Ion Pantographic Reach Truck 1.5 Ton Capacity.
The innovative WSRX15 with Lithium Ion boasts strong power, accurate control, excellent performance and a compact design to ensure high levels of productivity in your warehouse whilst the pantographic stroke extends the fork carriage beyond the units straddle legs, with integral tilt and sideshift for added versatility. Operation is both intuitive and low effort with easily accessible functions without having to lift your hand from the ergonomic handle. Maintenance is no problem with all key components conveniently placed within the back cover and control handle.
Productivity and ergonomics for heavy-duty operationwith a lift height of up to 5500mm and double-deep reach. Highly Maneuverable, Easily Serviceable, Broadly Flexible, Extremely Dependable
Load capacity
1500 kg
Lifting Height
max. 4800 mm
Drive Speed
max 6km/hr
Engine Output
max 3km/hr
Battery capacity
24 V / 205 Ah
Short charging times + intermittent charging capability
Powerful Lithium-Ion technology results in a long lasting, light weight and maintenance free battery. Extra service life and charge cycles over a conventional lead-acid battery. There are no costs for adapting the charging infrastructure for ventilation.
Achieve high levels of productivity
with the strong power and pantographic stroke of the WSRX coupled with accurate control and a compact design. The pantographic stroke extends the fork carriage beyond the units straddle legs with integral tilt and sideshift added for versatility.
Packed with safety features.
The WSRX features an emergency stop button within easy reach of the operator, electronic brake when the handle is raised and speed control when the forks are raised above 30cm. Neutral resisting roll back on ramps, safety reversing belly button to prevent crush injury and easy access horn are additional features that make the WSRX safe whilst remaining versatile.
Powerful performance
Less energy consumption. Greater performance. The long lasting and low maintenance lithium-ion battery will have you moving heavier and larger loads with ease, all whilst working to eliminate operator strain.
